Technical Data
| Measures: |
|
| Weight: |
| Tare (Car) |
29,0 t |
| Tare (Trailer) |
19,2 t |
| Maximum Load (M) |
40,3 t |
| Maximum Load (R) |
31,6 t |
| Capacity (Car): |
| Seating Places |
40 |
| Standing Places (6 passengers / m2) |
122 |
| Total |
162 |
|
| Dimentions: |
| Lenght (Car) |
16.240 mm |
| Lenght (Trailer) |
16.090 mm |
| Width |
2.789 mm |
| Height |
3.523 mm |
| Gauge |
1.435 mm |
| Capacity (Trailer): |
| Seating Places |
48 |
| Standing Places (6 passengers / m2) |
130 |
| Total |
178 |
|
| Performances (C+C): |
| Maximum Speed |
72 kms/h |
| Maximum Acceleration |
1,3 m/s2 |
| Medium Deceleration |
1,2 m/s2 |
| Emergency Deceleration |
1,4 m/s2 |
| Performances (C+T+C): |
| Maximum Speed |
72 kms/h |
| Maximum Acceleration |
1,0 m/s2 |
| Medium Deceleration |
1,0 m/s2 |
| Emergency Deceleration |
1,4 m/s2 |
|
| Brakes: |
| Service Brakes |
Electrodynamic (Rheostatic or Regenerative) |
| Emergency Brakes |
Pneumatic + Electromagnetic |
| Stopping Brakes |
Electropneumatic |
| Parking Brakes |
Spring Type, Incorporated in a Brake Cylinder |
| Electrical Characteristics: |
| Feeding Tension |
750 V dc |
| Power Instalada (per car) |
4 x 175 kW |
|
| Traction System: |
| Tension Ondulator with GTO |
| Three-Phase Asyncronous Motor with Double Squirrel Cage |
|
| Body: |
Self-Supporting Stainless Steal with High Strength Steel Top |
Portas – tipo ladeante, de comando electrónico |
|
| Bogie: |
| Type |
Twin-Motor |
| Primary Suspension |
Rubber, MEGI type |
|
| |
| Secundary Suspension |
Pneumatic Springs |
| Transmission Ratio |
1 : 7,45 |
|
|
