| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
2-6-0 T |
| Boiler Pressure |
10 kg/cm2 |
| Heating Surface |
Firebox: ---- m2
Tubes: ---- m2
Total: 76,97 m2 |
| Overheating Surface |
--- |
| Grid Surface |
1,05 m2 |
| Heating and Grid Surfaces Ratio |
73,30 |
| Speed Recorder |
Didn't Have |
| Coupled Wheels Diameter |
1.000 mm |
| Brake |
Vacuum and Manual |
| Lighting System |
Acetylene |
| Cylinder Lubrication |
Pump |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
350,0 mm |
| Stroke |
500,0 mm |
| Valve Gear |
Allan |
| Distribution Type |
Flat |
| Power (UIC) |
--- |
| Maximum Speed |
--- |
| Tractive Effort |
3.675 kgf |
| Adhesion Factor |
--- |
| Injection System: |
| 2 Friedmann Injectors |
Right Side: A. S. Z. 8
Left Side: A. S. Z. 8 |
|
