| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
2-8-2 T |
| Boiler Pressure |
14 kg/cm2 |
| Heating Surface |
Firebox: 8,51 m2
Tubes: 78,64 m2
Total: 87,15 m2 |
| Overheating Surface |
39 m2 |
| Grid Surface |
2,15 m2 |
| Heating and Grid Surfaces Ratio |
40,80 |
| Speed Recorder |
Didn't Have |
| Coupled Wheels Diameter |
1.020 mm |
| Brake |
Vacuum and Manual |
| Lighting System |
Acetylene |
| Cylinder Lubrication |
Pump |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
500,0 mm |
| Stroke |
500,0 mm |
| Valve Gear |
Walschaerts |
| Distribution Type |
Cylindric |
| Power (UIC) |
--- |
| Maximum Speed |
--- |
| Tractive Effort |
11.320 kgf |
| Adhesion Factor |
--- |
| Injection System: |
| 2 Friedmann Injectors |
Right Side: A. S. Z. 8
Left Side: A. S. Z. 8 |
|
