| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
0-4-0T |
| Boiler Pressure |
12 kg/cm2 |
| Heating Surface |
36,60 m2 |
| Overheating Surface |
--- |
| Grid Surface |
0,88 m2 |
| Heating and Grid Surfaces Ratio |
48,20 |
| Speed Recorder |
Doesn't have |
| Coupled Wheels Diameter |
810 mm |
| Brake |
Steam |
| Lighting System |
Acetylene and Petroleum |
| Cylinder Lubrication |
Grease Nipples |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
High Pressure: 310,0 mm
Low Pressure: --- mm |
| Stroke |
430,0 mm |
| Valve Gear |
Walschaerts |
| Distribution Type |
Flat |
| Power (UIC) |
430 hp |
| Maximum Speed |
30 kms/h |
| Tractive Effort |
3.720 kg |
| Adhesion Factor |
--- |
| Injection System: |
| 2 Friedmann Injectors |
Right Side: A. S. Z. 9
Left Side: A. S. Z. 8 |
|
