| Mechanical Parts: |
Alsthom |
| Diesel Engine: |
S.A.C.M. |
| Transmission: |
Alsthom |
| Brake: |
Westinghouse |
_____________________________________
. |
| Locomotive Type |
AD 12 B |
| Power Output (Wheels) |
830 hp |
| Wheel Arrangement |
Bo' Bo' |
| Wheel Diameter (new) |
950 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
4 Stroke Cycle |
| Dead Man's Switch |
VACM |
| Multiple Working |
up to 3 |
| Wheel Flange Lubrification |
Lubrovia |
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
70 Km/h |
| Maximum Tractive Effort |
11.500 Kg |
| Continuous Tractive Effort |
10.600 Kg |
| Continuous Tractive Effort (Speed) |
21,5 Km/h |
| Tractive Effort at Max. Speed |
2.150 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
1 |
| Builder |
S.A.C.M. |
| Type |
MGO V 12 ASHR |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 12 |
| Bore and Stroke |
175 x 180 / 192 mm |
| Total Displacement |
54 l |
| Overfeeding |
Yes |
| Nominal Power |
1.050 hp |
| Nominal Speed |
1.500 rpm |
| Effective Power |
1.000 hp |
_____________________________________
. |
| Builder |
Alsthom |
| Type |
1 - Generator CC 830 H 10
4 - Traction Motors TA 641 M |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 79:14 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
