| Builders: |
| Mechanical Parts: |
Vossloh |
| Diesel Engine: |
EMD |
| Transmission: |
General Motors |
| Brake: |
Knorr |
_____________________________________
. |
| Traction: |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
400 kN |
| Continuous Tractive Effort |
244 kN |
| Continuous Tractive Effort (Speed) |
|
| Tractive Effort at Max. Speed |
|
| Dynamic Brake: |
| Maximum Effort (Wheels) |
|
| Corresponding Speed |
|
|
| Specifications: |
| Locomotive Type |
Euro4000 |
| Power Output (Wheels) |
|
| Wheel Arrangement |
Co' Co' |
| Wheel Diameter (new) |
1.067 mm |
| Driving Cabs (Number) |
2 |
| Air Brake |
Compressed Air |
| Dynamic Brake |
Rheostatic |
| Sanders (number) |
|
| Dead Man's Switch |
|
| Multiple Working |
Up to 3 |
| Wheel Flange Lubrification |
|
| Speed Recorder |
|
| Transmission Ratio |
71 : 18 |
| Supplies: |
| Oil |
1.075 l |
| Water |
750 l |
| Fuel |
7.000 l |
| Sand |
480 l |
|
| Measures: |
| Height |
4.264 mm |
| Width |
2.850 mm |
| Lenght |
23.020 mm |
| Tare |
125 t |
|
|
