| Mechanical Parts: |
Sorefame (Licenca Alsthom) |
| Diesel Engine: |
S.A.C.M. |
| Transmission: |
Alsthom |
| Brake: |
Knorr - Bremse |
_____________________________________
. |
| Locomotive Type |
AD 30 C |
| Power Output (Wheels) |
2.260 hp |
| Wheel Arrangement |
Co' Co' |
| Wheel Diameter (new) |
1.100 mm |
| Driving Cabs (Number) |
2 |
| Air Brake |
Compressed Air |
| Dynamic Brake |
Alsthom |
| Sanders (number) |
8 |
| Dead Man's Switch |
Alsthom |
| Multiple Working |
up to 3 |
| Wheel Flange Lubrification |
Vogel |
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
100 Km/h |
| Maximum Tractive Effort |
39.600 Kg |
| Continuous Tractive Effort |
25.600 Kg |
| Continuous Tractive Effort (Speed) |
23,2 Km/h |
| Tractive Effort at Max. Speed |
6.180 Kg |
| Maximum Effort (Wheels) |
22.500 Kg |
| Corresponding Speed |
42,5 Km/h |
|
| Number |
1 |
| Builder |
S.A.C.M. |
| Type |
AGO - V12 DSHR |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 12 |
| Bore and Stroke |
240 - 220 / 230 mm |
| Total Displacement |
152,1 l |
| Overfeeding |
Yes |
| Nominal Power |
3.300 hp |
| Nominal Speed |
1.350 rpm |
| Effective Power |
3.300 hp |
_____________________________________
. |
| Builder |
Alsthom |
| Type |
1 - Alternator AT 53
6 - Traction Motors TAO 659 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 69:17 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
