| Mechanical Parts: |
Montreal Locomotive Works |
| Diesel Engine: |
MLW / Alco |
| Transmission: |
Canadian General Electric |
| Brake: |
Westinghouse Air Brake |
_____________________________________
. |
| Locomotive Type |
MX-620 |
| Power Output (Wheels) |
1.700 hp |
| Wheel Arrangement |
Co' Co' |
| Wheel Diameter (new) |
1.016 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
8 |
| Dead Man's Switch |
Davies & Metcalf |
| Multiple Working |
up to 2 |
| Wheel Flange Lubrification |
Doesn't have |
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
24.300 Kg |
| Continuous Tractive Effort |
19.300 Kg |
| Continuous Tractive Effort (Speed) |
22,5 Km/h |
| Tractive Effort at Max. Speed |
4.000 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
1 |
| Builder |
MLW / Alco |
| Type |
251 C 3 |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 12 |
| Bore and Stroke |
228,6 x 266,7 mm |
| Total Displacement |
131,4 l |
| Overfeeding |
Yes |
| Nominal Power |
2.180 hp |
| Nominal Speed |
1.050 rpm |
| Effective Power |
2.180 hp |
_____________________________________
. |
| Builder |
Canadian General Electric |
| Type |
1 - Generator CC 5GT 851-Pj1
6 - Traction Motors GE 761 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 92:16 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
