| Mechanical Parts: |
Alco |
| Diesel Engine: |
Alco |
| Transmission: |
General Electric |
| Brake: |
Knorr - Bremse |
_____________________________________
. |
| Locomotive Type |
RSC 3 |
| Power Output (Wheels) |
1.730 hp |
| Wheel Arrangement |
(A1A) (A1A ) |
| Wheel Diameter (new) |
1.016 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
8 |
| Dead Man's Switch |
Doesn't have |
| Multiple Working |
Doesn't have |
| Wheel Flange Lubrification |
Tipo FIAT |
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
17.200 Kg |
| Continuous Tractive Effort |
21.000 Kg |
| Continuous Tractive Effort (Speed) |
21 Km/h |
| Tractive Effort at Max. Speed |
3.800 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
1 |
| Builder |
Alco |
| Type |
251 C |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 12 |
| Bore and Stroke |
228,6 x 266,7 mm |
| Total Displacement |
131,4 l |
| Overfeeding |
Yes |
| Nominal Power |
2.185 hp |
| Nominal Speed |
1.025 rpm |
| Effective Power |
2.185 hp |
_____________________________________
. |
| Builder |
General Electric |
| Type |
1 - Generator CC 5GT 564-C1
6 - Traction Motors 5GE752-A1 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 65:18 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
