| Mechanical Parts: |
Sorefame (Licence: English Electric) |
| Diesel Engine: |
English Electric |
| Transmission: |
English Electric |
| Brake: |
Westinghouse Brake and Signal |
_____________________________________
. |
| Locomotive Type |
LD 844 C |
| Power Output (Wheels) |
970 hp |
| Wheel Arrangement |
Bo' Bo' |
| Wheel Diameter (new) |
950 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
8 |
| Dead Man's Switch |
Davies Metcalf Oerlinkon |
| Multiple Working |
up to 3 (compatible with 1800) |
| Wheel Flange Lubrification |
Lubrovia |
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
105 Km/h |
| Maximum Tractive Effort |
16.100 Kg |
| Continuous Tractive Effort |
14.200 Kg |
| Continuous Tractive Effort (Speed) |
19 Km/h |
| Tractive Effort at Max. Speed |
2.400 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
1 |
| Builder |
English Electric |
| Type |
8 CSVT |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
8 V |
| Bore and Stroke |
254,0 x 304,8 mm |
| Total Displacement |
123,5 l |
| Overfeeding |
Yes |
| Nominal Power |
1.340 hp |
| Nominal Speed |
850 rpm |
| Effective Power |
1.330 hp |
_____________________________________
. |
| Builder |
English Electric |
| Type |
1 - Generator CO EE 819
4 - Traction Motors EE 548 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 72:15 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
