| Mechanical Parts: |
Compañia Euskalduna |
| Diesel Engine: |
Alco |
| Traction Motors: |
General Electric |
| Transmission: |
General Electric |
| Brake: |
Wabco-Dimetal |
_____________________________________
. |
| Locomotive Type |
ALCo DL535S (RSD39) |
| Power Output (Wheels) |
1.389 hp |
| Wheel Arrangement |
(A 1 A) (A 1 A) |
| Wheel Diameter (new) |
1.016 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Rheostatic |
| Sanders (number) |
|
| Dead Man's Switch |
|
| Multiple Working |
up to 2 |
| Wheel Flange Lubrification |
|
| Speed Recorder |
Hasler |
_____________________________________
. |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
21.400 Kg |
| Continuous Tractive Effort |
18.480 Kg |
| Continuous Tractive Effort (Speed) |
13 Km/h |
| Tractive Effort at Max. Speed |
1.850 Kg |
| Maximum Effort (Wheels) |
14.060 Kg |
| Corresponding Speed |
30 Km/h |
|
| Builder |
Alco |
| Type |
251 D |
| Working Cycle |
4 Stroke Cycle |
| Disposição e Número de Cylinders |
6 Lv |
| Bore and Stroke |
228 x 267 mm |
| Total Displacement |
58,5 l |
| Overfeeding |
|
| Nominal Power |
1.216 hp |
| Nominal Speed |
1.100 rpm |
| Effective Power |
1.216 hp |
_____________________________________
. |
| Builder |
General Electric |
| Type |
1 Generator GT-581E
4 Traction Motors 5 GE- 761 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 92:19 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
