| Mechanical Parts: |
The Whitcombe Locomotive Company |
| Diesel Engine: |
Superior |
| Transmission: |
Westinghouse |
| Brake: |
Westinghouse Air Brake |
_____________________________________
. |
| Locomotive Type |
0-6-6-0 |
| Power Output (Wheels) |
1020 hp |
| Wheel Arrangement |
(A 1 A) (A 1 A) |
| Wheel Diameter (new) |
1.016 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
DUAL (Air & Vacuum) |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
8 |
| Dead Man's Switch |
Doesn't have |
| Multiple Working |
Doesn't have |
| Wheel Flange Lubrification |
Doesn't have |
| Speed Recorder |
Chicago Pneumatic |
_____________________________________
. |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
15.900 Kg |
| Continuous Tractive Effort |
11.140 Kg |
| Continuous Tractive Effort (Speed) |
27 Km/h |
| Tractive Effort at Max. Speed |
1.800 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
2 |
| Builder |
Superior |
| Type |
40 B-Lx |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
6 Lv |
| Bore and Stroke |
216 x 266 mm |
| Total Displacement |
58,5 l |
| Overfeeding |
Yes |
| Nominal Power |
675 hp |
| Nominal Speed |
1.100 rpm |
| Effective Power |
675 hp |
_____________________________________
. |
| Builder |
Westinghouse |
| Type |
1 - Generator CC 1604-D
4 - Traction Motors 362 - RZ |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 65:18 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
