| Mechanical Parts: |
Sorefame (Licence: Brissonneau et Lotz) |
| Diesel Engine: |
Ste. Alsacienne de Constructions Mecaniques |
| Transmission: |
Brissonneau et Lotz |
| Brake: |
Frein Jourdain Monneret |
_____________________________________
. |
| Locomotive Type |
040 DE |
| Power Output (Wheels) |
600 hp |
| Wheel Arrangement |
Bo' Bo' |
| Wheel Diameter (new) |
1.100 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
Compressed Air |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
4 Stroke Cycle |
| Dead Man's Switch |
Brissonneau et Lotz |
| Multiple Working |
Doesn't have |
| Wheel Flange Lubrification |
Lubrovia |
| Speed Recorder |
1201-1215: RBM
1216-1225: Hasler |
_____________________________________
. |
| Maximum Speed |
80 Km/h |
| Maximum Tractive Effort |
16.000 Kg |
| Continuous Tractive Effort |
12.200 Kg |
| Continuous Tractive Effort (Speed) |
13 Km/h |
| Tractive Effort at Max. Speed |
1.800 Kg |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Number |
1 |
| Builder |
S.A.C.M. |
| Type |
M.G.O. V 12 ASHR |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 12 |
| Bore and Stroke |
175 x 180 mm |
| Total Displacement |
54 l |
| Overfeeding |
Yes |
| Nominal Power |
825 hp |
| Nominal Speed |
1.500 rpm |
| Effective Power |
825 hp |
_____________________________________
. |
| Builder |
Brissonneau et Lotz |
| Type |
1 - Generator CC B.L. 668 - 31
4 - Traction Motors 453 - 29 |
| General Characteristics |
Nose Suspended
Forced Ventilation
Transmission Ratio: 69:16 |
_____________________________________
. |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
