| Prime Mover: |
| Number |
2 |
| Builder |
Caterpillar |
| Type |
D 17000 |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
V 8 |
| Bore and Stroke |
146 x 203 mm |
| Total Displacement |
27,3 l |
| Overfeeding |
Doesn't have |
| Nominal Power |
190 hp |
| Nominal Speed |
1.000 rpm |
| Effective Power |
190 hp |
|
| Transmission: |
| Builder |
General Electric |
| Type |
2 - Generators CC GT - 555 - A
4 - Traction Motors with GE 733 Reducers |
| General Characteristics |
Nose Suspended
Autoventilated
Transmission Ratio: 8,72 |
| Heating Equipment: |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
