| Builders: |
| Mechanical Parts: |
Gaston Moyse |
| Diesel Engine: |
Gaston Moyse |
| Transmission: |
Gaston Moyse |
| Brake: |
Whestinghouse |
| Traction: |
| Maximum Speed |
38 Km/h |
| Maximum Tractive Effort |
7.000 Kg |
| Continuous Tractive Effort |
7.000 Kg |
| Continuous Tractive Effort (Speed) |
4 Km/h |
| Tractive Effort at Max. Speed |
0 Kg |
| Dynamic Brake: |
| Maximum Effort (Wheels) |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Specifications: |
| Locomotive Type |
BA |
| Power Output (Wheels) |
120 hp |
| Wheel Arrangement |
B |
| Wheel Diameter (new) |
1.050 mm |
| Driving Cabs (Number) |
1 |
| Air Brake |
Compressed Air |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
4 Stroke Cycle |
| Dead Man's Switch |
Moyse |
| Multiple Working |
Doesn't have |
| Wheel Flange Lubrification |
Doesn't have |
| Speed Recorder |
Moyse - Indication Only |
| Transmission Ratio |
8,72 |
|
