| Prime Mover: |
| Number |
1 |
| Builder |
Gardner |
| Type |
8 L 3 |
| Working Cycle |
4 Stroke Cycle |
| Cylinder Number and Arrangement |
8 Lv |
| Bore and Stroke |
139,7 x 196,9 mm |
| Total Displacement |
24 l |
| Overfeeding |
Doesn't have |
| Nominal Power |
200 hp |
| Nominal Speed |
1.200 rpm |
| Effective Power |
200 hp |
|
| Transmission: |
| Builder |
Self Changing - V. Sinclair |
| Type |
1 - Gearbox Wilson CA5
1 - Hydraulic Coupling
1 - Inverter Bridge RF 11 |
| General Characteristics |
Wheels connected by Rods
Transmission Ratio: 5,32 |
| Heating Equipment: |
| Builder |
Doesn't have |
| General Characteristics |
Doesn't have |
|
