| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
2-6-2 T |
| Boiler Pressure |
12 kg/cm2 |
| Heating Surface |
Firebox: 11,64 m2
Tubes: 120,12 m2
Total: 131,83 m2 |
| Overheating Surface |
n/a |
| Grid Surface |
2,44 m2 |
| Heating and Grid Surfaces Ratio |
54 |
| Speed Recorder |
--- |
| Coupled Wheels Diameter |
1.546 mm |
| Brake |
Vacuum e manual |
| Lighting System |
Acetylene and Petroleum |
| Cylinder Lubrication |
Pump and Grease Nipples |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
High Pressure: 460,0 mm
Low Pressure: --- mm |
| Stroke |
600,0 mm |
| Valve Gear |
Walschaert |
| Distribution Type |
Flat |
| Power (UIC) |
--- |
| Maximum Speed |
--- |
| Tractive Effort |
5.913 kg |
| Adhesion Factor |
--- |
| Injection System: |
| 2 Friedmann Injectors |
Right Side: A.S.Z. 9
Left Side: A.S.Z. 8 |
|
