| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
2-8-4 T |
| Boiler Pressure |
12 kg/cm2 |
| Heating Surface |
Firebox: 13,31 m2
Tubes: 141,09 m2
Total: 154,40 m2 |
| Overheating Surface |
54,97 m2 |
| Grid Surface |
3,02 m2 |
| Heating and Grid Surfaces Ratio |
51,12 |
| Speed Recorder |
--- |
| Coupled Wheels Diameter |
1350 mm |
| Brake |
Vacuum, Steam and Manual |
| Lighting System |
Acetylene and Petroleum |
| Cylinder Lubrication |
Pump |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
High Pressure: 530,0 mm
Low Pressure: --- |
| Stroke |
660,0 mm |
| Valve Gear |
Walschaert |
| Distribution Type |
Cylindric |
| Power (UIC) |
--- |
| Maximum Speed |
--- |
| Tractive Effort |
10.877 kg |
| Adhesion Factor |
--- |
| Injection System: |
| Pump |
Knorr |
| 2 Friedmann Injectors |
Right Side: A.S.Z. 10
Left Side: A.S.Z. 8 |
|
