| Specifications: |
| Locomotive Type |
Tank Locomotive |
| Wheel Arrangement |
0-4-0T |
| Boiler Pressure |
10 kg/cm2 |
| Heating Surface |
Firebox: 2,50 m2
Tubes: 26,80 m2
Total: 29,30 m2 |
| Overheating Surface |
--- |
| Grid Surface |
0,63 m2 |
| Heating and Grid Surfaces Ratio |
46,50 |
| Speed Recorder |
Didn't have |
| Coupled Wheels Diameter |
800 mm |
| Brake |
Manual |
| Lighting System |
Acetylene and Petroleum |
| Cylinder Lubrication |
Grease Nipples |
|
| Traction: |
| Cylinders |
2 |
| Cylinder Bore |
High Pressure: 225,0 mm
Low Pressure: n/a |
| Stroke |
400,0 mm |
| Valve Gear |
Stephenson |
| Distribution Type |
Flat |
| Power (UIC) |
--- |
| Maximum Speed |
--- |
| Tractive Effort |
1.518 kg |
| Adhesion Factor |
--- |
| Injection System: |
| 2 Friedmann Injectors |
Right Side: A.S.Z. 9
Left Side: A.S.Z. 8 |
|
