| Builders: |
| Mechanical Parts: |
Alsthom |
| Diesel Engine: |
S.F.A.C |
| Transmission: |
Alsthom |
| Brake: |
WABCO |
| Traction: |
| Maximum Speed |
90 Km/h |
| Maximum Tractive Effort |
4.500 Kg |
| Continuous Tractive Effort |
2.850 Kg |
| Continuous Tractive Effort (Speed) |
36 Km/h |
| Tractive Effort at Max. Speed |
570 Kg |
| Dynamic Brake: |
| Maximum Effort |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Specifications: |
| Trainset Type |
U.D.D. |
| Nominal Power (Wheels) |
281 hp |
| Wheel Arrangement |
B' 2' + 2' 2' |
| Wheel Diameter (new) |
880 mm |
| Driving Cabs (Number) |
2 |
| Air Brake |
Compressed Air PBA 2 |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
4 Stroke Cycle |
| Dead Man's Switch |
Davies & Metcalfe |
| Multiple Working |
up to 3 |
| Wheel Flange Lubrification |
Rail - Lubrovia |
| Speed Recorder |
Hasler |
| Transmission Ratio |
6,25:1 |
|
