| Builders: |
| Mechanical Parts |
Sorefame |
| Electric Equipment |
Groupement D'Electrification 50hz |
| Transmission |
Siemens, AEG, Oerlikon |
| Brake |
Jourdain Monneret |
_____________________________________
. |
| Traction: |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
11.600 Kgf |
| Continuous Tractive Effort |
6.800 Kgf |
| Continuous Tractive Effort (Speed) |
63 Km/h |
| Tractive Effort at Max. Speed |
1.500 Kgf |
| Dynamic Brake: |
| Esforço Máximo |
6.450 Kgf |
| Corresponding Speed |
95 Km/h |
|
| Specifications: |
| Trainset Type |
U.T.E. |
| Nominal Power (Wheels) |
2.360 hp |
| Wheel Arrangement |
2' 2' + Bo' Bo' + 2' 2' |
| Wheel Diameter (new) |
(M)1.000mm / (R)850mm |
| Driving Cabs (Number) |
2 |
| Air Brake |
Compressed Air- PBA25 |
| Dynamic Brake |
Groupement |
| Sanders (number) |
8 |
| Dead Man's Switch |
Oerlikon - Sifa |
| Multiple Working |
up to 3 |
| Wheel Flange Lubrification |
4 (Lubrovia Especial) |
| Speed Recorder |
Hasler |
| Transmission Ratio |
107 : 21 |
|
