| Builders: |
| Mechanical Parts: |
FIAT |
| Diesel Engine: |
FIAT |
| Transmission: |
N/A |
| Brake: |
Compressed Air, Westinghouse type, automatic and adjustable |
_____________________________________
. |
| Traction: |
| Maximum Speed |
120 Km/h |
| Maximum Tractive Effort |
N/A |
| Continuous Tractive Effort |
N/A |
| Continuous Tractive Effort (Speed) |
N/A |
| Tractive Effort at Max. Speed |
N/A |
| Dynamic Brake: |
| Maximum Effort |
Doesn't have |
| Corresponding Speed |
Doesn't have |
|
| Specifications: |
| Trainset Type |
Foguete |
| Nominal Power (Wheels) |
1.010 hp |
| Wheel Arrangement |
(1 A) 2' + 2' (A 1) |
| Wheel Diameter (new) |
910 mm |
| Driving Cabs (Number) |
2 (per Car/Trailer) |
| Air Brake |
Compressed Air |
| Dynamic Brake |
Doesn't have |
| Sanders (number) |
8 |
| Dead Man's Switch |
N/A |
| Multiple Working |
N/A |
| Wheel Flange Lubrification |
N/A |
| Speed Recorder |
N/A |
| Transmission Ratio |
N/A |
|
