Class Number: 0301/0325 Number Built: 25 Year in Service: 1954/55 Power Type: Diesel-Electric Service Type: Regional Gauge: 1668 mm Pictures Gallery Multimedia Listen to the Horn's sound   Technical Data Builders: Mechanical Parts: N. V. Allan e Ca Diesel Engine: S.S.C.M. Transmission: Smit Brake: Jourdain Monneret _____________________________________ . Performance Figures: . Traction: Maximum Speed 100 Km/h Maximum Tractive Effort 12.900 Kg Continuous Tractive Effort 2.180 Kg Continuous Tractive Effort (Speed) 33 Km/h Tractive Effort at Max. Speed 700 Kg Dynamic Brake: Maximum Effort 146 KW Corresponding Speed N.A. Specifications: Trainset Type Allan Nominal Power (Wheels) 343 hp Wheel Arrangement Bo' Bo' Wheel Diameter (new) 920 mm Driving Cabs (Number) 2 Air Brake Vacuum Dynamic Brake Smit Sanders (number) 8 Dead Man's Switch Allan-Smit Multiple Working up to 2 Wheel Flange Lubrification 4 Stroke Cycle Speed Recorder Hasler Transmission Ratio 5,44 Traction Equipment Prime Mover: Number 2 Builder S.S.C.M Type "POYAUD" C6150T Working Cycle 4 Stroke Cycle Cylinder Number and Arrangement 6 L H Bore and Stroke 150 x 180 mm Total Displacement 19,08 l Overfeeding Doesn't have Nominal Power 240 hp Nominal Speed 1.800 rpm Effective Power 220 hp Transmission: Builder Smit Type 1 - Generator G40/35 4 - Traction Motors GT30/27 General Characteristics Bogie Suspended Forced Ventilation Transmission Ratio: 5,44 Heating Equipment: Builder Allan General Characteristics Car: Diesel Water Trailer: Webasto Boiler Weight and Capacity Supplies: Fuel 608 Kg Oil 2 x 60 Kg Cooling Water 2 x 80 Kg Sand 400 Kg W.C. Water 2 x 75 Kg Crew and Tools 200 Kg TOTAL 1.710 Kg Partial Weights Prime Mover 2.450 Kg Main Generator 1.480 Kg Traction Motor 760 Kg Bogie (Car) 9.850 Kg Bogie (Trailer) 6.500 Kg Weights: Car Trailer Total Tare 51.500 Kg 31.000 Kg 82.500 Kg In Running Order 56.500 Kg 31.000 Kg 84.200 Kg Normal Load 59.600 Kg 39.500 Kg 99.100 Kg Maximum Load 62.300 Kg 44.300 Kg 106.600 Kg Capacity: 1st Class 2nd Class Standing Car 24 50 34 Trailer -- 106 60 TOTAL 24 156 94 Luggage Capacity: 500 Kg TOTAL Capacity: 274 Return to the Technical Center
