| Builder |
Equimetal |
| Construction Year |
1980 |
| Max. Speed |
100-120 Km/h |
| Medium Tare |
22.900 Kg |
| Maximum Load |
57.100 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
26-48 t |
| Vacuum Brake |
Doesn't have |
| Max. Hand Brake |
15 t |
| Cylinders |
1 x 14'' |
| Brake-rod Adjuster |
DRV 2A - 600 |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
LA-3R |
| "Unloaded-Loaded" Valve |
VTA |
| Loading Capacity |
64.600 L |
|
