| Builder |
Consórcio/Arbel * + Equimetal ** + Metalsines *** |
| Construction Year |
1972 * + 1980 ** + 1988 *** |
| Max. Speed |
100 Km/h |
| Medium Tare |
21.100 Kg * + 20.800 Kg ** + 21.600 Kg *** |
| Maximum Load |
58.900 Kg * + 59.200 Kg ** + 58.400 Kg *** |
| Wheels |
1.000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 218 mm |
| KE GP Brake |
23-43 t * + 22-41 t ** + 23-49 t *** |
| Max. Hand Brake |
12 t * + 12 t ** + 26 t *** |
| Cylinders |
2 x 10'' * + 2 x 12'' ** + 2 x 12'' *** |
| Brake-rod Adjuster |
DA 2 - 450 |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
LC3 - R / LAB3 - R * + LAB3-R ** e *** |
| Loading Capacity |
40 m3 |
