| Builder |
Metalsines |
| Proprietário |
Tejo Energia |
| Detentor |
CP Carga |
| Construction Year |
1992 e 1995 |
| Max. Speed |
120 Km/h |
| Medium Tare |
28.600 Kg |
| Maximum Load |
51.400 Kg |
| Wheels |
920 mm |
| Axle Bearing |
MBU 130 Cartridge |
| Axle Journal |
130 x 191 mm |
| KE GP Brake |
28-57 t |
| Vacuum Brake |
Doesn't have. |
| Max. Hand Brake |
22 t |
| Cylinders |
2 x 12'' |
| Brake-rod Adjuster |
DRV 2A - 300 |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
VTA |
| Loading Capacity |
80 m3 |
|
