| Builder |
Consórcio |
| Construction Year |
1972 |
| Max. Speed |
100 Km/h |
| Medium Tare |
20.500 Kg |
| Maximum Load |
59.500 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Cartuchos TBU 130-SKF |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
23-48 t |
| Max. Hand Brake |
5 - 21 t |
| Mudança de Regime Aut. |
42 t |
| Cylinders |
1 x 16'' |
| Brake-rod Adjuster |
DRV |
| Triple Valve |
C3W IV-GP |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
VTA |
| Floor Space |
35 m2 |
|
