| Builder |
Metalsines |
| Construction Year |
1993 / 2000 |
| Max. Speed |
120 Km/h |
| Medium Tare |
32,500 Kg |
| Maximum Load |
68.400 Kg |
| Wheels |
920 mm |
| Axle Bearing |
MBU 130 Cartridge |
| Axle Journal |
130 x 191 mm |
| Brake 2x Ke GP |
Max. 91 t |
| Max. Hand Brake |
21 t |
| Cylinders |
3 x 12'' |
| Brake-rod Adjuster |
3 x DRV 2A - 450 |
| Triple Valve |
Simple 1 KE 2a/3.8 SL-ALB
Dual 1 KERa/3.8 - KLSn |
| Load-Proportional Valve |
3 x WM 10 |
| Pneumatic Relays |
3 x RLV - 11d8/1 |
|
