| Builder |
Consórcio |
| Construction Year |
1973 |
| Max. Speed |
120 Km/h |
| Medium Tare |
28.000 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| Brake Ch GP |
34 t |
| Vacuum Brake |
29-40 t |
| Max. Hand Brake |
13 t |
| Cylinders |
2 x 12'' (Air Brake) + 2 x 21'' (Vaccum) |
| Brake-rod Adjuster |
2 x DRV 2A - 250 |
| Triple Valve |
KE C1 |
| "Unloaded-Loaded" Box |
LB3-R |
| "Unloaded-Loaded" Valve |
VTB |
|
