| Builder |
Franco Belga * / Sepsa Cometna ** |
| Construction Year |
1969 * / 1977 ** |
| Max. Speed |
100 Km/h |
| Medium Tare |
22.600 Kg * / 23.900 Kg ** |
| Maximum Load |
57.100 Kg * / 56.100 Kg ** |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
30-60 t |
| Vacuum Brake |
n/a |
| Max. Hand Brake |
7-21 t |
| Cylinders |
2 x 21'' |
| Brake-rod Adjuster |
DRV 2A |
| Triple Valve |
KE 1C SL |
| "Unloaded-Loaded" Box |
LAB |
| "Unloaded-Loaded" Valve |
VTA |
| Floor Space |
51,2 m2 * / 52 m2 ** |
|
