| Builder |
Metalsines |
| Construction Year |
1989 |
| Max. Speed |
120 Km/h |
| Medium Tare |
13.900 Kg |
| Maximum Load |
26.100 Kg |
| Wheels |
1.000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
15-26 t |
| Vacuum Brake |
Removed. Has passage pipe. |
| Max. Hand Brake |
22 t |
| Automatic Regime Change |
22 t |
| Cylinders |
1 x 12'' |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
C3W LVGP |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
VA 2 |
| Floor Space |
35,6 m2 |
| Volume |
59 m3 |
|
