| Builder |
MetalSines |
| Construction Year |
1989 |
| Modified by |
MetalSines |
| Modification Year |
2003 |
| Max. Speed |
120 Km/h |
| Medium Tare |
11.900 Kg |
| Maximum Load |
28.100 Kg |
| Wheels |
1.000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake - A |
15 - 26 t |
| Max. Hand Brake |
22 t |
| Cylinders |
1 x 12'' |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
C3W LV-GP |
| "Unloaded-Loaded" Box |
LAB3 - R |
| "Unloaded-Loaded" Valve |
VA 2 |
|
