| Builder |
Franco-Belga |
| Construction Year |
1969 |
| Max. Speed |
100 Km/h |
| Medium Tare |
12.600 Kg |
| Maximum Load |
27.400 Kg |
| Wheels |
1000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| Brake Ch GP |
14-26 t |
| Mudança de Regime Aut. |
22 t |
| Max. Hand Brake |
25 t |
| Cylinders |
1x12 '' |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
KE 1C SL |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
VA2 |
| Floor Space |
34,6 m2 |
|
