| Builder |
Yesmering |
| Construction Year |
1970 |
| Modified by |
CP/EMEF |
| Modification Year |
2005 |
| Max. Speed |
100 Km/h |
| Medium Tare |
14.200 Kg * + 16.300 Kg ** |
| Maximum Load |
25.800 Kg * + 23.700 Kg ** |
| Wheels |
1.000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
17-26 t |
| Max. Hand Brake |
21 t |
| Cylinders |
1 x 12'' |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
KE 1c SL * / C3W LV GP ** |
| "Unloaded-Loaded" Box |
LS3-KA TYPE |
| "Unloaded-Loaded" Valve |
MV Type |
| Floor Space |
33 m2 |
|
