| Builder |
SEPSA |
| Construction Year |
1977 |
| Modified by |
SEPSA |
| Modification Year |
1988/89 |
| Max. Speed |
100 Km/h |
| Medium Tare |
13.500 Kg |
| Wheels |
1000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 |
| Brake Ch GP |
14-24 |
| Vacuum Brake |
13-23 |
| Max. Hand Brake |
8 |
| Cylinders |
1x12 (Air brake) e 1x24 (Vacuum) |
| Brake-rod Adjuster |
DRV 2 - 450 |
| Triple Valve |
KE 1C SL |
| "Unloaded-Loaded" Box |
LAB |
| "Unloaded-Loaded" Valve |
VA2 e VB2 |
| Loading Capacity |
60 m3 |
|
