| Builder |
2 00 (Entroncamento) |
| Construction Year |
1958/59 |
| Modified by |
SEPSA |
| Modification Year |
1988/89 |
| Max. Speed |
100 Km/h |
| Medium Tare |
12.800 Kg |
| Maximum Load |
23.200 Kg |
| Wheels |
1000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 |
| Ch GP Brake |
13-24 |
| Vacuum Brake |
15-21 |
| Max. Hand Brake |
11 |
| Cylinders |
1x10 (Air Brake) e 1x10 (Vacuum) |
| Brake-rod Adjuster |
DA 2 - 450 |
| Triple Valve |
KE 1C SL |
| "Unloaded-Loaded" Box |
LC3-R |
| "Unloaded-Loaded" Valve |
Manual |
| Loading Capacity |
63,7 m3 |
|
