| Builder |
Wagonfabrik Gebr_Luitgens |
| Construction Year |
1943 |
| Modificados |
CP / EMEF-GOE |
| Modification Year |
1993/94 |
| Max. Speed |
100 Km/h |
| Medium Tare |
33.000 Kg |
| Maximum Load |
22.000 Kg |
| Wheels |
970 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
120 x 175 mm |
| KE GP Brake |
39 t |
| Vacuum Brake |
Doesn't have |
| Max. Hand Brake |
13 t |
| Cylinders |
3 x 10'' |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
Doesn't have |
| "Unloaded-Loaded" Valve |
Doesn't have |
| Floor Space |
80 m2 |
|
