| Builder |
Sepsa-Cometna |
| Construction Year |
1977 |
| Modified by |
Oficinas do Entroncamento |
| Modification Year |
|
| Max. Speed |
100 Km/h |
| Medium Tare |
28.000 Kg |
| Maximum Load |
50.900 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 210 mm |
| KE GP Brake |
34-46 t |
| Vacuum Brake |
|
| Max. Hand Brake |
7-18 t |
| Cylinders |
1 x 16'' |
| Brake-rod Adjuster |
DRV 2A |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
LAB |
| "Unloaded-Loaded" Valve |
VTA |
| Loading Capacity |
110 m3 |
| Floor Space |
52 m2 |
|
