| Builder |
Metalsines |
| Construction Year |
1997 |
| Max. Speed |
120 Km/h |
| Medium Tare |
24.400 Kg |
| Maximum Load |
65.600 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 191 mm |
| KE GP - A Brake |
28 - 78 t |
| Max. Hand Brake |
15 t |
| Cylinders |
2 x 12'' |
| Brake-rod Adjuster |
DRV 2A - 300 |
| Triple Valve |
KE 1c SL |
| Load-Proportional Valve |
WM 10 |
| "Unloaded-Loaded" Box |
LAB3-R |
| "Unloaded-Loaded" Valve |
VTA |
| Loading Capacity |
47.000 L |
|
