| Builder |
Franco-Belga |
| Construction Year |
1969 |
| Max. Speed |
100 Km/h |
| Medium Tare |
11.600 Kg |
| Wheels |
1.000 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 |
| KE GP Brake |
11-22 |
| Vacuum Brake |
Removed (has passage pipe) |
| Max. Hand Brake |
20 Ton |
| Cylinders |
1x10 |
| Brake-rod Adjuster |
DRV 2A - 450 |
| Triple Valve |
C3W IV-GP |
| "Unloaded-Loaded" Box |
LAB-3R |
| "Unloaded-Loaded" Valve |
VA 2 |
| Floor Space |
24,2 m2 |
| Loading Capacity |
30 m3 |
|
