| Builder |
Sepsa-Cometina |
| Construction Year |
1976 |
| Max. Speed |
100 Km/h |
| Medium Tare |
33.800 Kg |
| Maximum Load |
56.300 Kg |
| Wheels |
920 mm |
| Axle Bearing |
Roller Bearing |
| Axle Journal |
130 x 217 mm |
| KE GP Brake |
22-45 t |
| Vacuum Brake |
Removed (has passage pipe) |
| Max. Hand Brake |
7 t |
| Cylinders |
1 x 16'' |
| Brake-rod Adjuster |
DRV 2A - 600 |
| Triple Valve |
KE 1c SL |
| "Unloaded-Loaded" Box |
LAB-3R |
| "Unloaded-Loaded" Valve |
VTA |
| Floor Space |
35,3 m2 |
| Loading Capacity |
72 m3 |
|
