| Builder |
De Dietrich Cie Reichshoffen |
| Construction Year |
1967 (Modified 1991) |
| Max. Speed |
160 Km/h |
| Medium Tare |
53.500 Kg |
| Maximum Load |
6.000 Kg |
| Capacity |
40 |
| Wheels |
920 mm |
| Axle Bearing |
Conical Bearing |
| Axle Journal |
130 x 217 mm |
| O-P Brake |
81 Ton |
| Max. Hand Brake |
7 t |
| Brake-rod Adjuster |
Block built-in |
| Triple Valve |
C3W |
| Brake Disks |
640 x 110 mm |
| Climatization |
"Faiveley" Air Conditioning Unit |
| Lighting |
Incandescent and Fluorescent |
| Doors |
Manual Opening |
| Batteries |
Nickel-Cadmium 110 and 24 V |
|
